Facts F4-16AD-2 Analog Voltage Input Module

Module Type:Analog Voltage Input

Channels:16

Resolution:12-bit

Signal Compatibility:Single-ended

Termination:Common

Operating Voltage Range:VCC

Power Supply:Internal/External

Power Consumption:≤80 mA at 5 VDC

Voltage Output Range:0 to 5 VDC or 0 to 10 VDC

Maximum Output Current:10 mA

Wiring Mechanism:7.62 mm fixed terminal block

    Engineered for precision, the Facts F4-16AD-2 Analog Voltage Input Module ensures accurate signal conversion for industrial environments. With 16 single-ended channels terminating into a single common, it seamlessly integrates with DirectLogic 405 series controllers and external devices, facilitating efficient data exchange.

    The module’s robust design allows it to operate within specified electrical limits, ensuring reliable performance under various conditions. It supports two output ranges—0 to 5 VDC and 0 to 10 VDC, catering to diverse application requirements.

    Backed by a 12-bit resolution, the F4-16AD-2 provides high accuracy in signal conversion, enabling precise control over industrial processes. Its voltage sourcing output with a maximum of 10 mA further enhances its versatility in different system configurations.

    For optimal performance, the module requires a minimum power supply of 80 mA at 5 VDC and an external supply between 21.6 and 26.4 VDC. Proper installation and storage practices are crucial to maintain its longevity, with a recommended climate-controlled environment for best results.

    Designed for durability and reliability, the Facts F4-16AD-2 is an essential component for any industrial control system seeking enhanced signal processing capabilities. Its compatibility with the DirectLogic 405 series ensures seamless integration and efficient operation within complex industrial setups.
